Geysertech Pi2R Micro geyser solar unit

DESCRIPTION

The Pi²R is an innovative new technology that feeds your existing electrical geyser with two power sources ie. AC grid power and DC PV power. No need for backup batteries, the energy generated from two or three solar panels (depending on size of geyser and size of solar panel) is fed directly into the geyser and stored inside the geyser as heat energy.

The Pi²R converts the current from the PV modules to a modified wave which is safe to use in the existing element and thermostat. This modified wave form enables the thermostat to switch power on and off as if it were normal AC power. There is no need to replace the element or thermostat

The Pi²R Micro is the smaller of the two available Pi²R models and is generally paired with a geyser timer which is normally set to top up the temperature of the geyser from grid power, if necessary, in the early hours of the morning.

FEATURES

* Built in MPPT

* Suitable for geysers up to 3KW

* Generally paired withe a geyser timer

* SANS 10400 compli

SPECIFICATIONS

PV input voltage: 90-200 Vdc

Grid voltage: 200-240 Vac

Element size: 2-3 KW

Geyser capacity: 50-150 Litres

DOWNLOADS

Visit downloads for instructions and specifications
