SVOLT 5.43kWh Lithium Battery
SVOLT 5.43kWh Lithium Battery
Couldn't load pickup availability
Description
Excellent performance, capacity, and reliability from one of the top 10 lithium battery cell manufacturers in the world. The SVolt 51.2V 106AH 5.43kWh Lithium Ion Battery is manufactured utilizing premium A-Grade cell. Wall mounted or floor mounted and available in square or rectangular shape to suit your installation. SVOLT is the battery unit of Great Wall Motors.
Parallel up to 16 batteries to customise your capacity. Simple setup and flexible installation options. This highly efficient and reliable home battery can be installed either on the wall or on the floor, providing you with the convenience and flexibility of finding the best spot for your home.
Features
- A-Grade Cell Technology
- Fast Plug In & Plug Out Terminals
- Flexible installation - Wall or floor mount
- Built-in Battery Management System
- Multi layer protection and reliable BMS (battery management system)
- Parallel up to 16 units
- Simple and easy setup
- Sleek, ultra compact design - elegant white casing for wall mounting
Specifications
- Battery Type-Chemistry: LiFePO4
- Nominal Voltage: 51.2V
- Nominal Capacity: 106Ah
- Energy: 5.43kWh
- Dimensions: 598*360*155mm
- Weight(approx): 44.6kg
- Terminal Type: Fast Plug In & Plug Out
- Case Material: Metal SPCC
- BMS Built-in: Yes
- Internal Resistance: <25m ohm
- Efficiency – Round Trip: >97%
- Self Discharge per Month: <3%
- Max Parallel Connectors: 16Pcs
- Series Connections: Not Allowed
- Cycle Life(0.3C 25 C @ 90% DOD): >6000 Cycles
- Discharge Temperature: -20 C to 70 C
- Charge Temperature: -5 C to 65 C
- Storage Temperature: 0 C to 30 C
- Voltage Range: 43.2V - 57.6V
- Recommended Charge Voltage: 56.0V+-0.2V
- Max Charge Voltage: 58.4V +-0.20V
- Recommended Charge Current: 50A
- Max Continuous Charge Current: 100A
- Recommended Discharge Voltage: 44.8V +-0.20V
- Max Discharging Voltage: 43.2V +-0.20V
- Max Continuous Discharge Current: 100A
- Peak Discharge Current: 150A (100ms)
- Communication protocol: RS485, CAN
- Warranty: 5 year product warranty with 10 year performance guarantee
